The JUKI placement machine KE2080 is a general-purpose placement machine that has both high-speed placement capabilities for small components  high-precision placement capabilities for ICs  complex-shaped heterogeneous components. At the same time, CHIP high-speed placement  precision placement of special-shaped components are realized.

Product Name: JUKI placement machine KE-2080

Product introduction: General-purpose placement machine with high-speed placement capabilities of small components  high-precision placement capabilities of ICs  complex-shaped heterogeneous components. At the same time, CHIP high-speed placement  precision placement of special-shaped components are realized.

Detailed equipment parameters JUKI placement machine KE-2080

■ Chip components 20,200CPH (laser identification / ** condition) (0.178 seconds / chip) 16,700CPH (laser identification / IPC9850)

■ High-speed placement performance

■ Highly stable placement head device  high-resolution axis control

■ Z / θ independent control

■ High-quality airless placement technology

■ Widely applicable to various components

■ Using universal image

■ User-friendly basic design

Substrate size:

For M substrate (330 × 250mm)

○ L substrate (410 × 360mm)

○ L-wide (510 × 360mm)

○ For E substrate (510 × 460mm) * 1

○ Element size: Laser recognition 0402 (01005 inch) chip to 33.5mm square element

Image recognition 1.0 × 0.5mm * 2 ～ 74mm square element  50 × 150mm element

Mounting speed: chip components ** condition 0.178 seconds / chip (20,200CPH) IPC985016,700CPHIC components * 31,850CPH4,600CPH * 4 components

JUKI placement machine KE-2080

Mounting accuracy: laser recognition ± 0.05mm (Cpk ≧ 1)

Image recognition ± 0.03mm (± 0.04mm when using MNVC (optional))

Component placement types: * more than 80 types (converted to 8mm tape) * 5
