Introduction to Hand Mounter Failure Analysis Troubleshooting

The installation method of the second-hand chip mounter in the high-precision chip mounter we use the instructions for the use of the components, the Shenzhen chip mounter is integrated with the machine. In the placement of components the process method of use, the placement machine is the use of dedicated components methods, sucked out in a tray placed on a feeding platform, then the feeding platform is moved to the position of the placement head for placement The head sucks mounts. The position of the suction placement components on the feeding platform can be set by machine parameters. In the subsequent production process, the problem of incorrect suction of the tray components has occurred. I have also used this method to solve similar problems existing in another unit of equipment.

The second-hand placement machine is based on our judgment that the problem is caused by software, so the hardware of the machine is checked. During the inspection process, the CCD camera was found to be loose! Fix the CCD camera tightly reset the relevant parameters of the machine. Similar problems did occur after re-production. Since the SMT equipment, especially the placement machine, has a large vibration during the production process, it is necessary to check the fixation of some devices on the machine frequently. Installation in the operating system market), manufacturers have set some parameters on the hard disk, ordinary hard disk can install system software. The most important point is that for some current SMT devices, the software operating system version is older. Shenzhen chip mounters manufacturers have encrypted their hard disks for various reasons. Once the hard disks are damaged, it will be a very troublesome problem. It is necessary to back up the hard disk if possible. At first we thought the bulb was damaged, but there was no response after replacing the new bulb. After further inspection, we found that the sensors that detect the presence of the printed board at the exit entrance of the reflow soldering also lost their response. By consulting the information we know that they are all supplied by a control power supply 15V voltage, check the control power supply's 15V output, found that there is no output, it is clear that the control power supply is damaged. We removed the control power supply opened it for inspection. We found that two 100UF electrolytic capacitors have become very bulging. It is estimated that they have been broken down by high voltage. Remove these two capacitors replace them with two new capacitors with large voltage resistance. Use a multimeter to check that the 15V voltage output is normal. Reinstall the control power supply. Turn on the power of the device after checking that the reflow soldering is normal.
